Tipo de rodamiento: dos rodamientos de bolas
material:; impulsor y;Marco: plástico (ul94v - 0)
plomo:; ul 1007 awg26
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Electrodo positivo de línea roja (+)
NbspNbspNbspNbspNbspNbspNbspNbspNbspNbsp;Electrodo negativo de alambre negro一)
peso: 42,0 G
| MODEL | Bearing System | Rated Voltage | Input Current | Power Consum ptlon (watts) | Speed | Noise |
| PART NO | B/S/F | VDE | AMP | watts | RPM | Db-A |
| WSA09015_05L | B/S/F | 5 | 0.35 | 1.75 | 2000 | 32 |
| WSA09015_05M | B/S/F | 5 | 0.5 | 2.5 | 3000 | 36 |
| WSA09015_12L | B/S/F | 12 | 0.2 | 2.4 | 2500 | 32 |
| WSA09015_12M | B/S/F | 12 | 0.35 | 4.2 | 3000 | 36 |
| WSA09015_12H | B/S/F | 12 | 0.55 | 6.6 | 3500 | 39.5 |
| WSA09015_24L | B/S/F | 24 | 0.2 | 4.8 | 2500 | 32 |
| WSA09015_24M | B/S/F | 24 | 0.3 | 7.2 | 3000 | 36 |
| WSA09015_24H | B/S/F | 24 | 0.4 | 9.6 | 3500 | 39.5 |
